GD Series Solar Inverters
Pure sine wave solar inverters from 4kW to 11kW, with MPPT charging, 24V or 48V battery configurations and support for operation without a battery.
- GD4024SMH
- GD6248SMH
- GD8648SMH
- GD11048SMH
- Rated output power
- 4000–11000 W
- Battery voltage
- 24 / 48 VDC
- Output voltage
- 220 / 230 / 240 ±5% VAC
- Solar charge controller
- MPPT
Tell us your quantity, market and product requirements.
PRODUCT INFORMATION
Product overview
GD SeriesThe GD Series offers four rated output options: 4000W, 6200W, 8600W and 11000W. It combines pure sine wave output, MPPT solar charging and selectable power-supply settings for PV, mains and battery operation.
GD4024SMH and GD6248SMH use a single MPPT configuration. GD8648SMH and GD11048SMH use dual MPPT inputs. The series supports operation without a battery; confirm the PV array and operating configuration for your application.
These four GD models are specified for standalone operation and do not support parallel connection. Wi-Fi and lithium battery BMS communication are available through expansion options; discuss the accessories and battery settings required for your project.
TECHNICAL INFORMATION
Product specifications
Compare models below. On smaller screens, scroll the table horizontally.
| Parameter | GD4024SMH | GD6248SMH | GD8648SMH | GD11048SMH |
|---|---|---|---|---|
| Rated output power — battery mode (W) | 4000 | 6200 | 8600 | 11000 |
| Output power — PV mode (W) | 4500 | 6500 | 11000 | 12000 |
| Peak output power (VA) | 8000 | 12400 | 17200 | 22000 |
| Battery voltage (VDC) | 24 | 48 | 48 | 48 |
| Constant charging voltage (VDC) | 28.2 | 56.4 | 56.4 | 56.4 |
| Float charging voltage (VDC) | 27 | 54 | 54 | 54 |
| MPPT configuration | Single | Single | Dual | Dual |
| PV input power, maximum (W) | 6500 | 8500 | 2 × 6500 | 2 × 7500 |
| MPPT input voltage range (VDC) | 60–500 | 60–500 | 90–500 | 90–500 |
| Optimal Vmp range (VDC) | 300–400 | 360–430 | 360–430 | 360–430 |
| PV input current, maximum (A) | 27 | 27 | 27 / 27 | 27 / 27 |
| PV charging current, maximum (A) | 120 | 120 | 150 | 150 |
| AC charging current, maximum (A) | 100 | 100 | 150 | 150 |
| Grid-connected rated output current (A) | 17.4 | 26.9 | 37.4 | 47.8 |
DOCUMENTATION & ENQUIRIES
Product support
Documents & resources
Contact our team for model-specific specifications, manuals and available supporting documents.
Questions & answers
Can the GD Series operate without a battery?
Yes. The series supports operation without a battery. Confirm the PV input requirements and system configuration with our team.
Can these GD models be connected in parallel?
No. GD4024SMH, GD6248SMH, GD8648SMH and GD11048SMH are specified for standalone operation.
Which GD models have dual MPPT inputs?
GD8648SMH and GD11048SMH have dual MPPT inputs. GD4024SMH and GD6248SMH use a single MPPT configuration.
