ED Series Solar Inverters
Pure sine wave solar inverters from 1.6kW to 11kW, with MPPT solar charging and 12V, 24V or 48V battery configurations. Compare five ED models in one place.
- ED2012EMH
- ED3024EMH
- ED4024EMH
- ED6248EMH
- ED11048EMH
- Rated output power
- 1600–11000 W
- Battery voltage
- 12 / 24 / 48 VDC
- Output voltage
- 220 / 230 / 240 ±5% VAC
- Solar charge controller
- MPPT
Tell us your quantity, market and product requirements.
PRODUCT INFORMATION
Product overview
ED SeriesThe ED Series combines pure sine wave AC output with MPPT solar charging. Five models cover 1600W, 3000W, 4000W, 6200W and 11000W rated output, with battery voltage and PV input limits matched to each model.
The ED11048EMH uses dual MPPT inputs and supports parallel operation. The other four models are specified for standalone operation. Grid-connected specifications are listed for ED4024EMH, ED6248EMH and ED11048EMH; contact our team for the configuration of your chosen model.
The LCD shows operating mode, load and input/output information. Expansion options include Wi-Fi and lithium battery BMS communication; confirm the required accessories and battery settings when discussing your project.
TECHNICAL INFORMATION
Product specifications
Compare models below. On smaller screens, scroll the table horizontally.
| Parameter | ED2012EMH | ED3024EMH | ED4024EMH | ED6248EMH | ED11048EMH |
|---|---|---|---|---|---|
| Rated output power — battery mode (W) | 1600 | 3000 | 4000 | 6200 | 11000 |
| Output power — PV mode (W) | 1600 | 3000 | 4500 | 6200 | 12000 |
| Peak output power (VA) | 3200 | 6000 | 8000 | 12400 | 22000 |
| Battery voltage (VDC) | 12 | 24 | 24 | 48 | 48 |
| Constant charging voltage (VDC) | 14.1 | 28.2 | 28.2 | 56.4 | 56.4 |
| Float charging voltage (VDC) | 13.5 | 27 | 27 | 54 | 54 |
| MPPT configuration | Single | Single | Single | Single | Dual |
| PV input power, maximum (W) | 2000 | 3000 | 5000 | 6200 | 2 × 5500 |
| MPPT input voltage range (VDC) | 30–500 | 30–500 | 60–500 | 60–500 | 90–500 |
| Optimal Vmp range (VDC) | 300–400 | 300–400 | 300–400 | 300–400 | 300–400 |
| PV input current, maximum (A) | 13 | 13 | 18 | 18 | 18 / 18 |
| PV charging current, maximum (A) | 100 | 100 | 120 | 120 | 150 |
| AC charging current, maximum (A) | 60 | 60 | 100 | 100 | 150 |
| Combined charging current, maximum (A) | 100 | 100 | 120 | 120 | 150 |
| Parallel operation | Not supported | Not supported | Not supported | Not supported | Supported |
| Grid-connected output voltage (VAC) | Not listed | Not listed | 220 / 230 / 240 | 220 / 230 / 240 | 220 / 230 / 240 |
| Grid voltage range (VAC) | Not listed | Not listed | 170–265 | 170–265 | 170–265 |
| Grid frequency range (Hz) | Not listed | Not listed | 49–51 ±1 / 59–61 ±1 | 49–51 ±1 / 59–61 ±1 | 49–51 ±1 / 59–61 ±1 |
| Grid-connected rated output current (A) | Not listed | Not listed | 17.4 | 26.9 | 47.8 |
| Grid-connected power factor | Not listed | Not listed | >0.99 | >0.99 | >0.99 |
| Peak DC/AC conversion efficiency (%) | Not listed | Not listed | 98 | 98 | 98 |
DOCUMENTATION & ENQUIRIES
Product support
Documents & resources
Contact our team for model-specific specifications, manuals and available supporting documents.
Questions & answers
Which ED models support parallel operation?
ED11048EMH is specified to support parallel operation. ED2012EMH, ED3024EMH, ED4024EMH and ED6248EMH do not support parallel operation.
Does every ED model have dual MPPT?
No. ED11048EMH has dual MPPT inputs; the other four ED models have a single MPPT configuration.
How do I select the battery voltage?
ED2012EMH uses 12V, ED3024EMH and ED4024EMH use 24V, and ED6248EMH and ED11048EMH use 48V. Confirm battery charging settings and communication compatibility for your chosen model.
